8
―――――――――――――――――――――――――――
Chapter 1 Product Outline
――――――――――――――――――――――――
A Current
hour 1 hour/segment (bar graph)
min 1 minute/segment (bar graph)
Input over (bar graph)
⑬ Output terminal
Connected to the optional 9094 output cord to
provide output during a current measurement or a
frequency measurement in a current mode.
⑭ AC adapter connection terminal
Connected to the optional 9445-02 or 9445-03 AC
ADAPTER to perform measurements for no battery
or a long term measurement.
⑮ Voltage measurement terminal (V and COM
terminals)
Connected to the L9207-10 TEST LEAD (red and
black, supplied with the unit) to measure voltage.
⑯ Slide knob
Slide up to use the voltage measurement terminal or
slide down to use the output terminal or AC adapter
connection terminal. Move until a click is heard.
⑰ Back case
To replace the battery, remove the two screws.
⑱ Hand strap
Attach to get a better grip on the unit.
