15
―――――――――――――――――――――――――――
Chapter 2 Measurement Procedure
――――――――――――――――――――――――
Fresh battery
Battery capacity 50%
Battery capacity 0
Beep tone sounds 3 time
Chapter 2
Measurement
Procedure
2.1 Preparations
1. Remove the rear cover and insert a battery. (Refer to
"Chapter 4 Battery Replacement".)
2. Press
POWER
to turn the unit on. Verify that all
segments of the display light up briefly. Then the
model name is shown, and the bar graph indicates
the battery condition.
3. The DC current measurement mode is activated.
【Low battery voltage detection function】
After the
mark lights and battery voltage drops
below a certain level, the power goes off
automatically. When this occurs, bAtt and Lo are
displayed.
When power goes off after display of these marks,
replace the exhausted battery with a new one.
