Hioki 3285 - Chapter 3 Specifications; 3.1 Measurement Specifications; 3.1.1 Current Measurement Specifications

43
―――――――――――――――――――――――――――
Chapter 3 Specifications
――――――――――――――――――――――――
Temperature and humidity
for guaranteed accuracy
23℃±5℃ (73 ±9 ),
80% RH or less
Guaranteed accuracy period 1 year, or opening and closing of
the Clamp Sensor 10,000 times,
whichever comes first
Range
(Accuracy Range)
Resolution
DC
200A(10.0～200.0A) 0.1A ±(1.3%rdg.+3dgt.)
2000A(100～2000A) 1A ±(1.3%rdg.+3dgt.)
Range
(Accuracy Range)
Resolution
45～66Hz 10～45,66～1kHz
200A(10.0～200.0A) 0.1A ±(1.3%rdg.+3dgt.) ±(2.0%rdg.+5dgt.)
2000A
(100～1800A)
1A
±(1.3%rdg.+3dgt.) ±(2.0%rdg.+5dgt.)
(1800～2000A) ±(2.3%rdg.+3dgt.)
Range
(Accuracy Range)
Resolution
DC,45～66Hz 10～45,66～1kHz
200A(10.0～200.0A) 0.1A ±(1.3%rdg.+13dgt.) ±(2.0%rdg.+7dgt.)
2000A
(100～1800A)
1A
±(1.3%rdg.+13dgt.) ±(2.0%rdg.+7dgt.)
(1800～2000A) ±(2.3%rdg.+13dgt.)
Chapter 3
Specifications
3.1 Measurement Specifications
3.1.1 Current Measurement S
p
ecifications
○ Current display accuracy
① DC current A (mean value)
② AC current Arms (true rms)
③ AC+DC current Arms (true rms)
