22
―――――――――――――――――――――――――――
Chapter 2 Measurement Procedure
――――――――――――――――――――――――
REC (Record output)
(Auto power-off inactive)
MON (Waveform output)
(Auto power-off inactive)
Light turned off
(Auto power-off active)
Range /DIV 10 mV 20 mV 50 mV 0.1 V 0.2 V 0.5 V 1V
2000 A range 20 A 40 A 100 A 200 A 400 A 1000 A 2000 A
200 A range 2A 4A 10 A 20 A 40 A 100 A 200 A
※ The figures are current values per DIV of a measuring instrument,
such as a recorder.
WARNING
To avoid damage to the unit, do not short the
output terminal and do not input voltage to the
output terminal.
NOTE
3.
OUTPUT
switches the output modes.
4. Set a range based on the unit's measurement range
and other instruments, such as recorders. A
conversion table for ranges is provided below.
･ Before using the output function, be sure to press
OUTPUT
, confirming that either
REC
or
MON
annunciator is on. Output is made even when both
annunciators are off, but the power will be
automatically off in approximately 10 minutes, since
the auto power-off function is activated.
･ If
OUTPUT
is pressed in an auto range (AUTO),
the current range is set as the key is pressed.
(AUTO annunciator is turned off.)
･ Errors may occur or output values unless an auto-
zero-adjustment is done in DC A mode.
･ The zero-cancel function does not affect output.
Thus, voltage would be generated because of an
ambient temperature, even if there is no input.
