50
―――――――――――――――――――――――――――
Chapter 3 Specifications
――――――――――――――――――――――――
Bar graph display 35 segments
Over-range display "O.L." (bar graph)
Battery low warning
Data hold annunciator
HOLD
Auto power-off
annunciator
APS
Units A, V, Hz
Zero suppression 5 counts
Display update rate Digital counter
NORMAL approx. 2 times/second
SLOW approx. 1 time/3 seconds
FAST approx. 4 times/second
Bar graph approx. 4 times/second
Display response time
(the range is fixed,
0% to 100%)
Current, Voltage: 1 s max.
Frequency:
1 s max. (1000 Hz, 100 Hz range)
2.5 s max. (10 Hz range)
Range switching Auto range, manual (fixed) range
(selectable).
Output impedance 300Ω max.
Circuit dynamic
characteristics
(crest factor)
2.5 max. (1.42 for 2000 A range, 1.7 for
600 V range)
Withstand voltage Clamp sensor - Chassis, clamp sensor -
circuit: 5312 Vrms AC for 15 seconds
Effect of conducted
radio-frequency
electromagnetic field
(in 3 V)
Current measurement: -3 A or less
Location for use Indoor, altitude up to 2000 m
