Inserting/Replacing Batteries
Screwdriver
Battery Cover
Rear
1
Have the following items
available and ready.
•
Phillips screwdriver
•
LR6 Alkaline battery × 4
2
Turn off the device and
remove the measurement
cables or test leads from
the device.
3
Remove the protector. (p.24)
4
Unscrew the screws of the
battery cover with a phillips
screwdriver.
5
Remove the battery cover.
Do not remove the
waterproof seal from the
battery cover.
6
When replacing the batteries,
all of the old batteries should
be removed.
7
Pay attention to the
polarities of the batteries
when inserting 4 new
batteries (LR6).
8
Reattach the battery cover
onto the device and tighten
the screws.
9
Attach the protector. (p.24)
