Precise Measurement for Earth Resistance
(Precise Measurement Method, Three-pole Method)
Stowing
1
Press the button to turn it off.
2
Remove the measurement
cables from the measurement
terminals and t the cover of the
measurement terminal.
3
Remove the measurement cables
from the auxiliary earthing rods
and pull out the auxiliary earthing
rods without bending them.
(See p.55 for how to pull out.)
4
Rewind the measurement cables
(red, yellow) with the respective
winders and stow the winders in
the carrying case with the auxiliary
earthing rods inserted into the
winder's holders.
5
Remove the measurement cable
(black) from the earthing electrode
and fold it, and then stow it into
the carrying case. (p.20)
Always t the cover of the measurement terminals immediately
after use. Any foreign object entering the measurement terminal
may cause a failure.
