Hioki MEMORY HiLOGGER LR8450 Quick Start Manual

25
Part Names and Functions; Screens
Rear
33 44 5522
66
11
No. Name Functionality See
11
Installation screw
holes
The screws can be used for attaching the Z5040 Fixed Stand,
which allows the product to mount on a wall.
p. 17
22
Warning Contains important information about the instrument.
p. 40
33
Serial number The serial number consists of nine digits. The rst two digits
indicate the year of manufacture, while the second two digits
indicate the month of manufacture. Do not remove this sticker as
the number is important.
Communicate this number when you contact your authorized
Hioki distributor or reseller.
This label also indicates whether the instrument is an LR8450 or
an LR8450-01.
–
44
MAC address Indicates the MAC address assigned to your instrument. Do not
remove this sticker as the number is important.
–
55
External control
terminal names
Indicates the names of the external control terminals on the left
side of the instrument.
p. 65
66
Battery
compartments
Provides internal space for the Z1007 Battery Pack. (Up to 2)
p. 40
