Network load control
30
8.4
QoS/Priority
Basic - L3P
Release
4.0
11/07
Configuring Layer 2 management priority
Configure the VLAN ports to which the Switch sends management
packets as a member of the VLAN that sends data packets with a tag
(see on page 38 "Configuring VLANs").
Interface...................................... 1/2
Interface Shaping Rate......................... 50
Queue Id Min. Bandwidth Max. Bandwidth Scheduler Type
-------- -------------- -------------- --------------
0 10 20 Weighted
1 10 20 Weighted
2 15 20 Weighted
3 15 20 Weighted
4 20 20 Weighted
5 30 30 Weighted
6 0 30 Strict
7 0 30 Strict
Select the QoS/Priority:Global dialog.
In the line VLAN priority for management packets you enter
the value of the VLAN priority.
enable Switch to the Priviledged EXEC mode.
network priority dot1p-vlan
7
Assign the value 7 to the management priority so
that management packets with the highest priority
are sent.
exit Switch to the Priviledged EXEC mode.
show network Displays the management VLAN priority.
System IP Address.............................. 10.0.1.116Subnet
Mask.................................... 255.255.255.0Default
Gateway................................ 10.0.1.200Burned In MAC
Address.......................... 00:80:63:51:7A:80Network Config-
uration Protocol (BootP/DHCP).... NoneDHCP Client ID (same as SNMP
System Name)...... "PowerMICE-518280"Network Configuration Proto-
col HiDiscovery..... Read-WriteManagement VLAN
ID............................. 1Management VLAN Priori-
ty....................... 7Management IP-DSCP Val-
ue....................... 0(be/cs0)Web
Mode....................................... EnableJavaScript
Mode................................ Enable
