4.PARTS IDENTIFICATION
10
MARKS OF PARTS
1. Top Cover
2. Control Panel
3. Lifter
4. Drain Hose
5. Power Plug
6. Filter Cover Cap
7. Dispenser
8. Door
9. Drum
10. 4 Adjustable
Feet
11. Drain Pump
Filter
As for the product improvement and
expansion in series, products
purchased by you may differ from
the graphical representations in this
manual, the actual product shall
prevail.
The appearance depends on different machine models
Some models are not equipped with “U” elbow bracket or noise reduce board but not affect
the usa
e
IFU ASM 4 Plastic Caps Of
Trans
ortation Bolt
Inlet Tube+“U”
Elbow Bracket
Noise Reduce
Board
ACCESSORIES
To Next Page
