Hisense WFMC6010 - Heater

10.COMPONENT TESTING INFORMATION
42
10.5 INLET VALVE
Wiring
diagram
Function
The PCB will power on the pre-valve and main_valve as per the settings of
program, and fill water into the tub to reach the set water level.
Test points
and result
Test points Result Remarks
1-2 4.0-5.0K Pre_Valve
1-3 4.0-5.0K Main_Valve
Circuit in the PCB / Wiring Diagram
