11.DISASSEMBLY INSTRUCTIONS
50
11.8 MOTOR
4. Disassemble the damper pin as shown,
and look out the claw structure on the pin.
3. Unscrew 2 crews as shown，
disassemble the motor
1. Disassemble the belt as shown
3.Unscrew crew as shown，disassemble
the pulley
