Periodic Maintenance and Adjustment 8-9
Changing engine oil
1. Start the engine and allow to warm up
approximately 2 – 3 minutes then shut off.
2. Place an oil reclaim container under
the ATV.
3. Remove the oil drain bolt (1) and allow
the oil to drain into the container.
① Oil drainage bolt
4. Once the oil is drained re-install the oil
drain bolt (1) and tighten to the proper
torque.
Torque spec – Oil drain bolt
NOTE:
In order to avoid clutch slippage (because
the oil also lubricates the clutch), do not
mix any other chemicals with the oil.
Do not use “CD” standard oil or any other
standard higher than the specified oil. Do
not use “ENERGY CONVERSING II” oil or
other oils higher than this standard.
Without changing the oil filter:
2.01 US qt（1.67 lmp qt,1.90L ）
Changing the oil filter:
2.11 US qt（1.76lmp qt,2.00L ）
