Periodic Maintenance and Adjustment 8-25
Sheet 1: Body Panel troubleshooting
Panel damaged during
off-road driving
1. Check if the frame and support brackets are deformed or broken.
Repair and touch-up with paint as necessary
2. Replace any damaged body panels.
3. Re-attach new stickers and install warning placards with rivets.
1. Inspect bottom frame for damage and repair if needed
2. Inspect bottom of engine for damage, make sure there are no leaks,
repair if needed
3. Replace with new skid plate as necessary
Sheet 2: Brake system troubleshooting
1. Check if parking brake releases when returned to off position.
2. Check brake discs on front and rear wheels for deformation.
3. Inspect brake calipers on front and rear wheels. Inspect hydraulic
