Engl ish -33-
Si gnal Input
PC RGB Terminal (D-su b 15-pin con ne ctor)
Pin Input signal
1R
2 G or sync on green
3B
4 No connection
5 No connection
6R.GND
7G.GND
8B.GND
9 No connection
10 GND
11 No connection
12 [SDA]
13 H.sync or H/V composite sync
14 V.sync. [V.CLK]
15 [SCL]
• When different kinds of input signals are simul-
taneously input to the monitor via a graphics
board or the like, the monitor w ill automatically
selec t the sig n a l s in the following priority o r d er:
Sync signal type Priori ty
H/V separate sync. 1
H/V composite sync. 2
sync.on Green * 3
• Even in the case of the recommended signals
shown on the following page, there may be
instances when correct display is not pos-
sible. In this case, use H/V separate sync, H/
V composite sync.
S-in pu t conne ct or pin specif icatio ns
Pi n I nput signal
1Y
2Y-GND
3C
4C-GND
Frame GND
HDMI c onne ctor pin sp ec ifications
Pin Input signal Pin Input si gna l
1 TMDS Data2+ 11 TMDS Cloc k S hield
2 TMDS Data2 Shield 12 TMDS Clock-
3TMDSData2-13 CEC
4 T MDS Data 1+ 14 Reserved (N.C. on device)
5 TMDS Data1 Shield 15 SCL
6 TMDS Data1- 16 SDA
7 TMDS Data0+ 17 DD C/CED Ground
8 TMDS Data0 Shield 18 +5V Power
9 TMDS Data0- 19 Hot Plug Detect
10 T MDS Clock+
SCA RT connector pin specifications
Pin Input sig na l Pin Input sig na l
1 AUDIO OUT (RIGHT) 12 Not used
2 AUDIO IN (RIGHT) 13 RGB-R GND
3 AUDIO OUT (LEFT/MONO) 14 GND
4 AUDIO GND 15 RGB-R / S.VHS CHROMINANCE IN
5RGB-BGND16 BLANKINGSIGNAL
6 AUDIO IN (LEFT/MONO) 17 COMPOSITE VIDEO GND
7 RGB-B IN 18 BLANKING SIGNAL GND
8 AUDIO / RGB SWITCH / 16:9 19 COMPOSITE VIDEO OUT
9 RGB-G GND 20 COMPOSITE V IDEO / S.VHS LUMINANCE IN
10 Not used 21 GND / SHIELD (CHAS SIS)
11 RGB-G IN
Speci f icat io ns
