Hitachi 37LD8D20U - Rear View and Peripheral Connections; Connection Ports Overview; Port Descriptions

English -6-
Rear View and Peripheral Connections
S-VHS Input
Video Input
Audio Inputss
Headphone
AudioLineOutss
Subwoofer
TV/AVV
MENU
IR Receiver
Standby LED
2
20V-240V
AC~50 Hz
POWER
Note: Because FAV CVBS and SVHS Y are connected parallelly, the picture may blend if the two peripherals
are used at the same time. Likewise, because SVHS C and SCART II R are connected parallelly, the picture
may blend if the two peripherals are used at the same time. Thus these two are not to be used at the same
time.
-P/CH+
-VOLUM E+
STAND-BY
PC VGA Input
PC Audio Input
RF (Antenna)
Component Video Inputs (Y pBpr)
Component Audio Inputss
SCART 1
SCART 2
HDMI Input
For Service Use Only
Power On/Off Switch
Power Cord Input
CI Slot
