Item Description
Status Shows an operation state of the switch module among the following states.
Normal: In normal state.
Booting: In initialization state.
Warning: In warning state. See the event log list to check details.
Fault: In failed condition. See the event log list to check details.
-----: No switch module is installed.
LID Shows an LID (Identification LED) state among the following states.
ON: Powered on.
OFF: Powered off.
-----: No switch module is installed.
Type Shows the switch module name.
Table 2-138 Action buttons at the bottom
Item Description
LID ON Turns on LID (Identification LED) of a selected switch module. You can select
multiple switch modules to turn on those LIDs.
LID OFF Turns off LID (Identification LED) of a selected switch module. You can select
multiple switch modules to turn off those LIDs.
Power ON Powers on the selected switch module. You can select multiple switch
modules to power on those switch modules.
Power OFF Powers off the selected switch module. You can select multiple switch
modules to power off those switch modules.
Switch module
Switch module window provides a selected switch module operation status,
hardware information. You can perform its operations, including basic settings
for Hitachi 1 Gb LAN switch module (20 ports and 40 ports), Hitachi 1/10 Gb
LAN switch module, and starting Brocade 8 Gb fibre channel switch module
and Brocade 16 Gb/sec fibre channel switch module Web console.
Operating the Web Console
2-123
Hitachi Compute Blade 500 Series Web Console User's Guide
