Hitachi EHV+ Series User Manual

Chapter 1 Introduction
1 – 2
1.3 System overview
EHV+ series PLC is module type programmable controller shown in Figure 1.1.
1] Power supply module
2] CPU module
3
]
I/O modules
0 1 2 3 4 5 6 7 8 9 10
7] I/O controller No.1
7] I/O controller No.2
7] I/O controller No.3
7] I/O controller No.4
5
]
Ex
p
ansion base uni
t
6
]
Ex
p
ansion cable
5
]
Ex
p
ansion base uni
t
6
]
Ex
p
ansion cable
5
]
Ex
p
ansion base unit
6
]
Ex
p
ansion cable
5
]
Ex
p
ansion
b
ase unit
4
]
Basic base uni
t
1] Power supply module
1] Power supply module
1] Power supply module
1] Power supply module
1] Power supply module
7] I/O controller No.5
5
]
Ex
p
ansion base uni
t
6
]
Ex
p
ansion cable
6
]
Ex
p
ansion cable
Figure 1.1 EHV+ series System configuration diagram (EHV-CPU1102)
No. Device name Description of function
1] Power supply module Converts external power to DC5V for CPU and I/O modules through base unit.
2] CPU module Reads input signals, executes user application program and writes output signals.
3] I/O module
Many types of I/O modules are available such as digital input/output modules, analog
input/output modules, high-functional modules and communicate modules.
4] Basic base unit All modules are mounted to base unit. Basic and expansion base unit are common.
5] Expansion base unit All modules are mounted to base unit. Basic and expansion base unit are common.
6] Expansion cable 0.5m, 1m and 2m cable are available. The max. cable length 8m in total.
7] I/O controller Be sure to use each expansion base unit.
EHV-CoDeSys
EHV-CoDeSys is IEC61131-3 compliant programming software for EHV+ series PLC. “CoDeSys” is a Trademark of
the company 3S-Smart Software Solutions GmbH. “EHV-CoDeSys” is same tool as “CoDeSys” however, Hitachi
specific device description files and libraries are preinstalled.
