Chapter 2 Specifications
2 – 3
Table 2.2 List of system equipment ( 2 / 2 )
Product Type Specification I/O type Remarks
RTD input
module
EH-PT4 Signed 15 bits, 4 ch. Resistance Temperature Detector input, PT100/PT1000 AI 4 *3
Thermocouple
input module
EH-TC8 Signed 15 bits, 8 ch. Thermocouple input (K, E, J, T, B, R, S, N) AI 8 *3
High function EH-CU 2 ch. high-speed counter input, 100 kHz, 4 points open collector output EH-CU/E
and EH-CUE 1 ch. high-speed counter input, 100 kHz, 2 points open collector output EH-CU/E
communication EH-POS 1 axis pulse output positioning module EH-POS/4
module EH-SIO Serial interface module EH-SIO
EH-RMD Device Net master module, 256/256 words I/O, 8 units per CPU EH-RMP
EH-RMP PROFIBUS-DP master module, 256/256 words I/O, 8 units per CPU EH-RMP
EH-IOCD Device Net slave controller, 256/256 words I/O －
EH-IOCP PROFIBUS-DP slave controller, 208 words I/O －
Mounted
in CPU
position
Dummy
module
EH-DUM Module for empty slot Empty
EH-CB5A Expansion cable (0.5m) －
EH-CB10A Expansion cable (1m) －
Expansion
cables
EH-CB20A Expansion cable (2m) －
Relay terminal HPX7DS-40V6 Relay terminal block for 32/64-point module －
EH-CBM01W 32/64-point module cable, both ends connector (1m) －
EH-CBM03W 32/64-point module cable, both ends connector (3m) －
EH-CBM05W 32/64-point module cable, both ends connector (5m) －
EH-CBM10W 32/64-point module cable, both ends connector (10m) －
EH-CBM01 32/64-point module cable, open and connector end (1m) －
EH-CBM03 32/64-point module cable, open and connector end (3m) －
EH-CBM05 32/64-point module cable, open and connector end (5m) －
EH-CBM10 32/64-point module cable, open and connector end (10m) －
CBM-02 EM/H-200 compatible 32 point module cable, open and connector end (2m) －
CBM-05 EM/H-200 compatible 32 point module cable, open and connector end (5m) －
32/64 points
module cables
CBM-10 EM/H-200 compatible 32 point module cable, open and connector end (10m) －
EH-CUC01 Counter module cable, open and connector end (1m) －
EH-CUC02 Counter module cable, open and connector end (2m) －
EH-CUC03 Counter module cable, open and connector end (3m) －
EH-CUC04 Counter module cable, open and connector end (4m) －
Counter
module cables
EH-CUC05 Counter module cable, open and connector end (5m) －
Battery LIBAT-H Lithium battery for retentive data and RTC －
*3 Use solid or stranded copper cable of 22-14 AWG with torque 9 in.–lbs (1.02 Nm)
[ Installing restriction ]
EH-RMP/RMD can be mounted up to 8 units per CPU. Available position is from slot 0 to 7 of basic base only.
!
Caution
Due to limited capacity of power supply module, available module configuration depends on total current
consumption of mounted modules. Please select I/O module and base unit according to the current consumption
specified in following pages.
