Chapter 2 Specifications
2 – 63
Setting switch Support to analog data and digital data
No. Setup Function
1 2 Output range setting for ch.0 to 3
OFF OFF 0 to 10 V DC
ON OFF
OFF ON 0 to 22 mA
1, 2
ON ON 4 to 22 mA
3 4 Output range setting for ch.4 to 7
OFF OFF 0 to 10 V DC
ON OFF
OFF ON 0 to 22 mA
3, 4
ON ON 4 to 22 mA
5 Output filter
OFF Disable
5
ON Enable
6 Resolution
OFF 1/16384 (14 bits)
6
ON 1mV or 0.002mA
7 (System mode) 7
OFF Always OFF (Do not turn ON)
8 (System mode) 8
OFF Always OFF (Do not turn ON)
Current / voltage switch
Reference) The images is as follows when the output filter is valid.
(Output filter: Invalid) (Output filter: Valid)
[Highlighted part is factory default setting.]
Note) Be sure to set dip switches before use. The dip switches must be set while power off, otherwise setting status is not updated.
When the input range is changed, be sure to set current / voltage switch accordingly.
Resolution 1mV
0 to 10 V DC
10
V
3FFFH
(16383)
2710H
(10000)
0
1FFFH
(8191)
1388H
(5000)
5
4 to 22 mA
0 to 22 mA
Current and voltage switch
4 to 7 channel
Current
Voltage
Current / voltage switch
0 to 3 channel
Current
Voltage
90%
18ms or less
90%
Approx. 200ms
Resolution 1/16384
10
20
mA
0
3A2EH
(14894)
2710H
(10000)
1D17H
(7447)
1388H
(5000)
Resolution 1/16384
Resolution
0.002mA
22
22
mA
0
10
4
38E3H
(14563)
1F40H
(8000)
1174H
(4468)
0FA0H
(3000)
F830H
(-2000)
Resolution 1/16384
Resolution
0.002mA
20
