Chapter 2 Specifications
2 – 74
Specifications
Item Specification
Type EH-CU EH-CUE
Number of channels 2 1
Number of counts at the maximum 32 bits（0 to 4,294,967,295）
Maximum frequency 100 k Hz (25 k Hz at multiplied by 4)
Count mode Select by setting of DIP switch. (EH-CU is common to both channels.)
2-phase, 1-phase (CW/CCW, CK, U/D), 2-phase multiplied by 4
Differential input current 4 mA minimum
Differential input voltage 12 to 24V DC
Minimum ON voltage 10V DC
Minimum OFF voltage 4V DC
Insulation system Photo-coupler
A:A, CW, CK
B:B, CCW, U/D
Number of input
points
3 points / CH
M: Marker (z)
Phase difference of each channel (A – B) during 2-phase counting
+45° to +125° when up, -45° to -125° when down
Minimum counter pulse width ON: 4 μs, OFF: 4 μs
Minimum marker pulse width 10 μs (detected at ON edge)
External wiring method 30-pin connector
External wiring Wired with twisted pair cables and batch shielded cables
Output voltage 12/24 V DC (30 V DC at the maximum)
Load current 20 mA / point at the maximum
Output method Open collector output
Minimum load current 1 mA
ON → OFF 1 ms maximum Output delay time
OFF → ON 1 ms maximum
Voltage down at ON 1.5 V at the maximum
Number of external output points 4 2
Normal counter Current value = Set value 1, or Current value > Set value 1
Ring counter Current value = Set value 2
Leak current 0.5 mA at the maximum
Polarity (-) common within the module
External power supply 12/24 V DC (30 V DC at the maximum)
Insulation system Photo-coupler
Internal current consumption 310mA maximum
