Chapter 2 Specifications
2 – 81
Specifications
Item Specification
The number of modules 8 / CPU (slot 0 to 7 only)
Number of slaves Up to 124 slaves
Output data 256 words
Input data 256 words
Data transfer rate : Max segment length 9.6 kbps: 1200 m
19.2 kbps: 1200 m
93.75 kbps: 1200m
187.5 kbps: 1000m
500 kbps: 400m
1500 kbps: 200m
3 Mbps: 100m
6 Mbps: 100m
12 Mbps: 100m
Self-diagnosis System ROM/RAM check, watch-dog timer check
GSD file File name : Hms_1004.gsd
This file can either be downloaded from the webpage http://www.hms.se/fbfiles.htm
or received by contacting HMS Fieldbus AB.
Configurator Please prepare the configurator from HMS Fieldbus AB.
Order number: KONF-PDP
