7-36 ●Backing up data to USB memory
Detailed explanation of Classification No.2 (Table 2)
●The conditions of Print data are described in Table 3, which can be used when a part of setting is corrected.
Table 3. Conditions with which display color of Message name changes to Brown on "Select message" screen
No. Item Conditions and corrections
1DIN print
"DIN print" is NOT available on the lower model. "DIN print" of Print
data shall be set to [Disable] instead of [Enable]
2 Ink Drop Charge Rule
The lower model is a Basic machine. "Ink Drop Charge Rule" of Print
data shall be set to [Standard (single scan/interlaced)] instead of [Mixed
single scan and interlaced] or [Dot mixed interlaced].
3 Product speed matching
The lower model is a Basic machine. "Product speed matching" of Print
data shall be set to [None] instead of [Auto]
4 Print format
The lower model is a Basic machine. "Format Setup" of Print data shall be
set to [Individual setup] instead of [Free layout].
5 Line spacing
The lower model has NO setting for "Line spacing expansion".
[Line spacing] of Print data shall be set to "2" instead of "3 or greater".
6
Ink drop use
(High-speed print)
There are some Ink drop use rates which are NOT available on the lower
model. "Ink drop use" of Print data shall be set to the configurable value.
Set to [HM] for "High-speed print".
[NOTE]
●After executing Select message, correct and confirm the Print data. And then please overwrite and use it for
printing. (Display color of Message name on "Select message" screen changes from Brown to Black.)
Detailed explanation of Classification No.3 (Table 2)
●The conditions of Print data which can NOT be used are described in Table 4 below.
Table 4. Conditions with which display color of Message name changes to Red on "Select message" screen
No. Item Conditions
1 Number of Print lines Max Line of the lower model < Line of Print data
2 Max Character size Max Character size of the lower model < Character size of Print data
3 Min Character size Min Character size of the lower model > Character size of Print data
4 Printing columns Max Printing columns of the lower model < Printing columns of Print data
5 Calendar items Max Calendar items of the lower model < Calendar items of Print data
6 Replacement items
Max Replacement items of the lower model < Number of Substitution rules
of Print data
7 Count items Max Count items of the lower model < Count items of Print data
8
Bar code/
2D code print
Bar code is set, which CANNOT be set on the lower model.
2D code print is set, which CANNOT be set on the lower model.
9
Shift code
Time count
Shift code is set, which CANNOT be set on the lower model.
Time count is set, which CANNOT be set on the lower model.
10 User pattern
The lower model is a Basic machine, and the settings of 51st onward of
User patterns (Fixed) are made.
The lower model is a Basic machine and the settings of User patterns (Free)
are made.
To Next Page
