A-26
Monitor name
HOP, HRW DOP, DRW
Alterability
No. Data HRW DRW
Trip cause factor 1 ERR1 # ERR1 # Y d10 - - - N N
Trip frequency 1 ERR1 0.0 Hz ERR1 0.0 Hz N — — N N
Trip current 1 ERR1 0.0 A ERR1 0.0 A Y d10 - - - N N
Trip time P-N voltage 1 ERR1 0.0 Vdc ERR1 0.0 Vdc Y d10 - - - N N
Integrated count 1 of cause ERR1 R 0 Y 0 D ERR1 R 0 Y 0 D N — — N N
time running days
Integrated error count ERR COUNT 0 ERR COUNT 0 N — — N N
Trip cause 2 ERR2 # ERR2 # Y d11 - - - N N
Trip frequency 2 ERR2 0.0 Hz ERR2 0.0 Hz N — — N N
Trip current 2 ERR2 0.0 A ERR2 0.0 A N — — N N
Trip time P-N voltage 2 ERR2 0.0 Vdc ERR2 0.0 Vdc N — — N N
Integrated count of error ERR2 R 0 Y 0 D ERR2 R 0 Y 0 D N — — N N
time running days
Trip cause 3 ERR3 # ERR3 # Y d11 - - - N N
Trip frequency 3 ERR3 0.0 Hz ERR3 0.0 Hz N — — N N
Trip current 3 ERR3 0.0 A ERR3 0.0 A N — — N N
Trip time P-N voltage 3 ERR3 0.0 Vdc ERR3 0.0 Vdc N — — N N
Integrated count of error ERR3 R 0 Y 0 D ERR3 R 0 Y 0 D N — — N N
(2) Function mode Y: Possible
N: Not possible
Display with HOP, HRW Display with DOP, DRW
Function No. with digital operator
Data read/copy
Function mode
Layer Data display No. Data display
Alterability
No. Data HRW DRW
Frequency command 1- 1 F-SET 1: REM Monitor F-SET- Y F9 0 Y Y
SELECT REM
Operation command 2 F/R 1: REM Monitor F/R-SELECT Y Y
REM
Parameter selection 3 PARM 0: REM F-09 PARAM REM N — — Y Y
Trip history count clear 2- 1 TCNT 0: CNT F-38 INITTCNT CNT N — — Y Y
Debug mode display selection 2 DEBG 0: OFF INIT DEBG OFF N — — N N
Digital operator rotating direction 3 DOPE 0: FWD INIT DOPE RWD Y F4 F Y Y
selection
Reset performance selection 4 RESET 0: ON INIT RESET ON Y F86 0 Y Y
Base frequency setting
First setting 3-1-1 1 F-BASE 50 Hz F-00 F-BASE 0050 Hz Y A62 50 Y Y
Second setting 1 F-BASE 50 Hz F-BASE 0050 Hz Y A62 50 Y N
Max. frequency setting
First setting 2 F-MAX 50 Hz F-01 F-MAX 0050 Hz Y A63 50 Y Y
Second setting 2 F-MAX 50 Hz F-MAX 0050 Hz Y A63 50 Y N
Start frequency setting 3 Fmin 0.5 Hz F-02 Fmin 0.50 Hz Y A4 0. 50 Y N
Motor voltage setting 4 A-AC 0: 200 V F-03 AVR AC200 V Y F11 200 Y Y
AVR function ON/OFF during 5 A-DEC 0: ON AVR DEC ON N — — Y Y
deceleration
set
value
set
value
Display with Display with
Function No. with digital operator
Data read/copy
