A-31
Display with HOP, HRW Display with DOP, DRW
Function No. with digital operator
Data read/copy
Function mode
Layer Data display No. Data display
Alterability
No. Data HRW DRW
Transmission speed selection 4-7 1 BAUD
1:600 bps
F-46
COM BAUD 0600 bps
N——YN
Station number selection 2 NUMBER 1
COM NUMBER 01
N——YN
Bit length selection 3 LENGTH 0: 8 COM LENGTH 8 N — — Y Y
Parity ON/OFF selection 4 PAR-1 1: ON
COM PAR-SEL1 ON
N——YY
Odd/even parity selection 5 PAR-2 0: EVN
COM PAR-SEL2 EVN
N——YY
Stop bit length selection 6 STOPBIT 0: 2 COM STOPBIT 2 N — — Y Y
Relay output terminal RYA signal 4-8 1 RYA 3: RUN F-48
RELAY RYA RUN
N——YN
selection
Relay output terminal RYB signal 2 RYB 0: CST RELAY RYB CST N — — Y N
selection
Relay output terminal RYC signal 3 RYC 4: OTQQ RELAY RYC OTQ N — — Y N
selection
Extension function setting Setting only for digital operator Y F14 A 0 N N
Voltage command adjustment Setting only for digital operator Y A80 N N
Current command adjustment Setting only for digital operator Y A81 N N
set
value
