Hitachi L300P Series - Output Terminal Configuration

“C” Group: Intelligent Terminal Functions
Configuring Drive
Parameters
3–48
Output Terminal
Configuration
The inverter provides configuration for logic (discrete) and analog outputs, shown in the table
below.
The output logic convention is programmable for terminals [11], [12], and the alarm relay
terminals. The relay output terminals [11] and [12] default to normally open (active low), but
you can select normally closed (active high) for the terminals in order to invert the sense of the
logic. You can invert the logical sense of the alarm relay output as well.
“C” Function
Run
Mode
Edit
Lo Hi
Defaults
Units
SRW Display
Func.
Code
Name Description
–FE2
(EU)
–FU2
(US)
–FR
(JP)
C021 Terminal [11] function 12 programmable
functions
(13 functions for
–xFE2/–xFU2
models) available for
logic (discrete)
outputs (see next
section)
✘ ✔ 01
[FA1]
01
[FA1]
01
[FA1]
—
>C021 OUT-TM
11 FA1
C022 Terminal [12] function ✘ ✔ 00
[RUN]
00
[RUN]
00
[RUN]
—
>C022 OUT-TM
12 RUN
C026 Alarm relay terminal
function
✘ ✔ 05
[AL]
05
[AL]
05
[AL]
—
>C026 OUT-TM
AL AL
C027 [FM] signal selection
7 programmable
functions available
for analog outputs
(see after next
section)
✘ ✔ 00
output
freq.
00
output
freq.
00
output
freq.
—
>C027 FM-MONITOR
KIND A-F
C028 [AM] signal selection ✘ ✔ 00
output
freq.
00
output
freq.
00
output
freq.
—
>C028 AM-MONITOR
KIND A-F
C029 [AMI] signal selection ✘ ✔ 00
output
freq.
00
output
freq.
00
output
freq.
—
>C029 AMI-MON
KIND A-F
“C” Function
Run
Mode
Edit
Lo Hi
Defaults
Units
SRW Display
Func.
Code
Name Description
–FE2
(EU)
–FU2
(US)
–FR
(JP)
C031 Terminal [11] active
state
Select logic convention,
two option codes:
00 normally open N.O.
01 normally closed N.C.
✘ ✔ 00 00 00 —
>C031 OUT-TM
O/C-11 NO
C032 Terminal [12] active
state
✘ ✔ 00 00 00 —
>C032 OUT-TM
O/C-12 NO
C036 Alarm relay terminal
active state
✘ ✔ 01 01 01 —
>C036 OUT-TM
O/C-AL NC
