The following tables list the screw size of terminal and recommended torque for tightening for
each of the L300P inverter models (400V models are on the next page).
CAUTION: Fasten the screws with the specified fastening torque in the table below. Check for
any loosening of screws. Otherwise, there is the danger of fire.
Note 1: The recommended ring lug connector listing consists of wire size – screw size
format. The wire sizes are in AWG or mm
2
format. For AWG wire sizes, bolt sizes
for the ring lug centers are: #10, #12, 1/4”, 5/16”, and 1/2”. For metric wire sizes, bolt
sizes for the ring lug centers are: 6 = 6M, 8 = 8M, 10 = 10M
TIP: AWG = American Wire Gauge. Smaller numbers represent increasing wire thickness.
kcmil = 1,000 circular mils, a measure of wire cross-sectional area
mm
2
= square millimeters, a measure of wire cross-sectional area
Input
Volt age
Motor
Output
200V
Inverter
Models,
L300P
Screw size
of terminal
Ring Lug Connector *1 Torque
HP kW (AWG–bolt)
(mm
2
–bolt)
ft-lbs N-m
200V
2 1.5 –015LFU2 M4 14–#10 2–4 1.1 1.5
3 2.2 –022LFU2 M4 14–#10 2–4 1.1 1.5
5 3.7 –037LFU2 M4 10–#10 3.5–4 1.1 1.5
7.5 5.5 –055LFU2 M5 8–#12 5.5–5 1.8 2.5
10 7.5 –075LFU2 M5 6–#12 8–5 1.8 2.5
15 11 -110LFU2 M6 4–1/4 14–6 3.6 4.9
20 15 -150LFU2 M6 2–1/4 22–6 3.6 4.9
25 18.5 -185LFU2 M6 1 30–6 3.6 4.9
30 22 -220LFU2 M8 1–5/16 38–8 6.5 8.8
40 30 -300LFU2 M8 2–5/16 60–8 6.5 8.8
50 37 -370LFU2 M8 2–5/16 100–8 6.5 8.8
60 45 -450LFU2 M10 1–1/2 100–10 10.1 13.7
75 55 -550LFU2 M10 2/0–1/2 150–10 10.1 13.7
100 75 -750LFU2 M10 3/0–1/2 150–10 10.1 13.7
