L300P Inverter
Operations
and Monitoring
4–9
Terminal Listing Use the following table to locate pages for intelligent input and output material in this chapter.
[AL0] Relay common contact Contacts AL0–AL1, maximum loads:
250VAC, 2A; 30VDC, 8A resistive load
250VAC, 0.2A; 30VDC, 0.6A inductive load
Contacts AL0–AL2, maximum loads:
250VAC, 1A; 30VDC 1A max. resistive load
250VAC, 0.2A; 30VDC, 0.2A max. inductive load
Min. loads: 100 VAC, 10mA; 5VDC, 100mA
[AL1] Relay contact, normally
closed
[AL2] Relay contact, normally
open
Termin al N ame Description Ratings and Notes
Intelligent INPUTS Intelligent OUTPUTS
Symbol Code Name Page Symbol Code Name Page
RV 01 Reverse Run/Stop 4–11
RUN 00 Run signal 4–36
CF1 02 Multi-speed select, Bit 0 (LSB) 4–12 FA1 01 Freq. arrival type 1 –
constant speed
4–37
CF2 03 Multi-speed select, Bit 1 4–12
CF3 04 Multi-speed select, Bit 2 4–12 FA2 02 Freq. arrival type 2 –
over-frequency
4–37
CF4 05 Multi-speed select, Bit 3 (LSB) 4–12
JG 06 Jogging 4–15 OL 03 Overload advance notice signal 4–39
DB 07 External signal for DC injection
braking
4–16 OD 04 Output deviation for PID control 4–40
AL 05 Alarm signal 4–41
SET 08 Set (select) second motor data 4–17 FA3 06 Freq. arrival type 3 – at frequency 4–37
2CH 09 2-stage accel and decel 4–18 IP 08 Instantaneous power failure signal 4–43
FRS 11 Free-run stop 4–19 UV 09 Under-voltage signal 4–43
EXT 12 External trip 4–20 RNT 11 Run time over 4–46
USP 13 Unattended start protection 4–21 ONT 12 Power-ON time over 4–46
CS 14 Commercial power source 4–22 THM 13 Thermal alarm signal 4–47
SFT 15 Software lock 4–24 RMD 27 Run command source monitor
(–xFU2 and –xFE2 models only)
4–50
AT 16 Analog input voltage/current sel. 4–25
RS 18 Reset inverter 4–26
STA 20 Start (3-wire interface) 4–28
STP 21 Stop (3-wire interface) 4–28
F/R 22 FW, RV (3-wire interface) 4–28
PID 23 PID ON/OFF 4–29
PIDC 24 PID Reset 4–29
UP 27 Remote control Up func. 4–30
DWN 28 Remote control Down func. 4–30
UDC 29 Remote control data clearing 4–30
OPE 31 Operator control 4–31
SF1–7 32–38 Multi-speed bits 1 to 7 4–12
OLR 39 Overload restriction 4–32
ROK 49 Run enable for FW/RV
(–xFU2 and –xFE2 models only)
4–34
