Page #14 background imageLoading...
Page #14 background image
xii
UL
®
Cautions, Warnings, and Instructions
Wiring Warnings
for Electrical
Practices and
Wire Sizes
The Cautions, Warnings, and instructions in this section summarize the procedures necessary to
ensure an inverter installation complies with Underwriters Laboratories
®
guidelines.
WARNING: “Use 60/75°C Cu wire only” or equivalent.
WARNING: “Open Type Equipment.” For models L300P–900H to L300P–1320H.
WARNING: “Suitable for use on a circuit capable of delivering not more than 100,000 rms
symmetrical amperes, 240 V maximum.” For models with suffix L.
WARNING: “Suitable for use on a circuit capable of delivering not more than 100,000 rms
symmetrical amperes, 480 V maximum.” For models with suffix H.
Terminal Tighten-
ing Torque and
Wire Size
The wire size range and tightening torque for field wiring terminals are presented in the table
below.
Input
Voltage
Motor
Output
Inverter Models,
L300P
Wire Size Range (AWG)
Torque
HP kW ft-lbs N-m
200V
2 1.5 -015LFU2 14 1.1 1.5
3 2.2 -022LFU2 14 1.1 1.5
5 3.7 -037LFU2 10 1.1 1.5
7.5 5.5 -055LFU2 8 1.8 2.5
10 7.5 -075LFU2 6 1.8 2.5
15 11 -110LFU2 4 3.6 4.9
20 15 -150LFU2 2 3.6 4.9
25 18.5 -185LFU2 1 3.6 4.9
30 22 -220LFU2 1/0 6.5 8.8
40 30 -300LFU2 1/0 6.5 8.8
50 37 -370LFU2 1/0 || 1/0 6.5 8.8
60 45 -450LFU2 1/0 || 1/0 10.1 13.7
75 55 -550LFU2 2/0 || 2/0 AWG 10.1 13.7
100 75 -750LFU2 3/0 || 3/0 AWG 10.1 13.7
