L300P Inverter
xiii
Input
Volt age
Motor
Output
Inverter Models,
L300P
Wire Size Range (AWG)
Torque
HP kW ft-lbs N-m
400V
2 1.5 -015HFU2, HFE2 20 1.1 1.5
3 2.2 -022HFU2, HFE2 18 1.1 1.5
5 4.0 -040HFU2, HFE2 16 1.1 1.5
7.5 5.5 -055HFU2, HFE2 14 1.1 1.5
10 7.5 -075HFU2, HFE2 12 1.8 2.5
15 11 -110HFU2, HFE2 8 3.6 4.9
20 15 -150HFU2, HFE2 6 3.6 4.9
25 18.5 -185HFU2, HFE2 6 3.6 4.9
30 22 -220HFU2, HFE2 4 3.6 4.9
40 30 -300HFU2, HFE2 3 3.6 4.9
50 37 -370HFU2, HFE2 1 3.6 4.9
60 45 -450HFU2, HFE2 1 6.5 8.8
75 55 -550HFU2, HFE2 1/0 AWG 6.5 8.8
100 75 -750HFU2, HFE2 1/0 || 1/0 AWG 6.5 8.8
125 90 -900HFU2, HFE2 3/0 (1/0 || 1/0 AWG) 10.1 13.7
150 110 -1100HFU2, HFE2 2/0 || 2/0 AWG 10.1 13.7
175 132 -1320HFU2, HFE2 2/0 || 2/0 AWG 10.1 13.7
