16
A044/
A244
V/f characteristic curve selection
• 00 V/f constant torque
• 01 V/f variable torque
• 02 Intelligent sensorless vector control
02
A045 V/f gain setting 100.
A046/
A246
Automatic torque boost voltage gain 100
A047/
A247
Automatic torque boost slip gain 100
A051 DC braking enable
• 00 Disable • 01 Enable
00
A052 DC braking frequency setting 0.5
A053 DC braking wait time 0.0
A054 DC braking force during deceleration 0.
A055 DC braking time for deceleration 0.0
A056 DC braking / edge or level detection for [DB]
input
01
A061 Frequency upper limit setting 0.0
A062 Frequency lower limit setting 0.0
A063
A065
A067
Jump (center) frequency setting 0.0
A064
A066
A068
Jump (hysteresis) frequency width setting 0.5
A071 PID Enable
• 00 PID operation OFF
• 01 PID operation ON
00
A072 PID proportional gain 1.0
A073 PID integral time constant 1.0
A074 PID derivative time constant 0.0
A075 PV scale conversion 1.00
A076 PV source setting
• 00 [OI] terminal (current input)
• 01 [O] terminal (voltage input)
• 02 ModBus network
• 03 Calculate function output
00
A077 Reverse PID action
• 00 PID input = SP – PV
• 01 PID input = –(SP – PV)
00
Func.
Code
Name / Description
Default
Value
–FEF / –FU
Set
Value
