Hitachi SJ200 Series - C Group: Intelligent Terminal Functions

20
“C” Group: Intelligent Terminal Functions
B140 Over-current trip suppression
• 00 Disable • 01 Enable
00
B150 Carrier mode
• 00 Disable • 01 Enable
00
Func.
Code
Name / Description
Default
Value
–FEF / –FU
Set
Value
C001 Terminal [1] function Twenty-four option
codes available
(see page 23)
00
C002 Terminal [2] function 01
C003 Terminal [3] function 02 / 16
C004 Terminal [4] function 03 / 13
C005 Terminal [5] function 18 / 09
C006 Terminal [6] function 09 / 18
C011 Terminal [1] active state • 00 Normally open
[NO]
• 01 Normally
closed [NC]
00
C012 Terminal [2] active state 00
C013 Terminal [3] active state 00
C014 Terminal [4] active state 00 / 01
C015 Terminal [5] active state 00
C016 Terminal [6] active state 00
C021 Terminal [11] function Ten option codes
available
(see page 24)
01
C022 Terminal [12] function 00
C026 Alarm relay terminal
function
05
C028 [AM] signal selection Two option codes
available
(see page 24)
00
C031 Terminal [11] active state • 00 Normally open
(NO)
• 01 Normally
closed (NC)
00
C032 Terminal [12] active state 00
C033 Alarm relay terminal
active state
01
Func.
Code
Name / Description
Default
Value
–FEF / –FU
Set
Value
