“H” Group: Motor Constants Functions
C102 Reset selection
• 00 Cancel trip state at input signal ON transi-
tion, stops inverter if in Run Mode
• 01 Cancel trip state at signal OFF transition,
stops inverter if in Run Mode
• 02 Cancel trip state at input signal ON transi-
tion, no effect if in Run Mode
00
C141 Input A select for logic
output
Nine option codes
available
(LOG excluded),
see page 24
00
C142 Input B select for logic
output
01
C143 Logic function select
• 00 [LOG] = A AND B
• 01 [LOG] = A OR B
• 02 [LOG] = A XOR B
00
C144 Terminal [11] ON delay 0.0
C145 Terminal [11] OFF delay 0.0
C146 Terminal [12] ON delay 0.0
C147 Terminal [12] OFF delay 0.0
C148 Output relay ON delay 0.0
C149 Output relay OFF delay 0.0
Func.
Code
Name / Description
Default
Value
–FEF / –FU
Set
Value
H003/
H203
Motor capacity Factory set
H004/
H204
Motor poles setting
• 2 poles • 4 poles
• 6 poles • 8 poles
4
H006/
H206
Motor stabilization constant 100
H007/
H207
Motor voltage select Factory set
Func.
Code
Name / Description
Default
Value
–FEF / –FU
Set
Value
