Hitachi SJ200 Series

Inverter MODBUS RTU Driver
GP-Pro EX Device/PLC Connection Manual
31
1H)
• 1:1 Connection
• 1:n Connection
• The 5V output (Pin #6) on the GP-4107 is the power for the Siemens AG’s
PROFIBUS connector. Do not use it for other devices.
• In COM on the GP-4107, the SG and FG terminals are isolated.
Shield
Display
Termination
resistance
200Ω
SP
SN
External Device side
RJ45 connector
Signal name
5
6
Pin
Termination
resistance
200Ω
Pin
Signal name
NC
NC
GND(SG)
RS(RTS)
5V
NC
NC
FG
LINE(+)
LINE(-)
3
8
1
2
5
4
6
7
9
Shell
Display side
D-Sub 9pin (plug)
Shield
Display
Pin
Signal name
NC
NC
GND(SG)
RS(RTS)
5V
NC
NC
FG
LINE(+)
LINE(-)
3
8
1
2
5
4
6
7
9
Shell
Display side
D-Sub 9pin (plug)
Termination
resistance
200Ω
SP
SN
5
6
External Device side
RJ45 connector
Signal name
Pin
SP
SN
External Device side
RJ45 connector
Signal name
5
6
Pin
Shield
Termination
resistance
200Ω
