Hitachi SJ200 Series

Inverter MODBUS RTU Driver
GP-Pro EX Device/PLC Connection Manual
32
Cable Diagram 2
Display
(Connection Port)
Cable Notes
GP3000
*1
(COM1)
AGP-3302B (COM2)
ST
*2
(COM2)
LT (COM1)
*1 All GP3000 models except AGP-3302B
*2 All ST models except AST-3211A and AST-3302B
2A
COM port conversion adapter by Pro-face
CA3-ADPCOM-01
+
Terminal block conversion adapter by Pro-face
CA3-ADPTRM-01
+
User-created cable
Cable length: 250m or
less
*3
*3 Cable length for the connection with WJ200 series is within 500m.
2B User-created cable
GP3000
*4
(COM2)
*4 All GP3000 models except GP-3200 series and AGP-3302B
2C
Online adapter by Pro-face
CA4-ADPONL-01
+
Terminal block conversion adapter by Pro-face
CA3-ADPTRM-01
+
User-created cable
2D
Online adapter by Pro-face
CA4-ADPONL-01
+
User-created cable
IPC
*5
*5 Only the COM port which can communicate by RS-422/485 (2 wire) can be used.
)" IPC COM Port" (page 4)
2E
COM port conversion adapter by Pro-face
CA3-ADPCOM-01
+
Terminal block conversion adapter by Pro-face
CA3-ADPTRM-01
+
User-created cable
2F User-created cable
GP-4106 (COM1) 2G User-created cable
GP-4107 (COM1) 2H User-created cable
