Holding Register data configuration (3/13)
Word
address
Classification Item name Setting range Contents
10 28
Print format
Adjust Inter-character space
(Start)
1 to 500
Inter-character space can be set in
character units.
10 29
Adjust Inter-character space
(End)
1 to 500
10 2A
Adjust Inter-character space
(Setting value)
0 to 28
10 2B Reserve_1
-
"Reserve" is not initially provided,
but may be added in future.
… …
10 3E Reserve_20
10 3F Format Setup 1 to 3
Sets the Format Setup.
1:Individual setup , 2:Overall setup
3:Free layout
10 40 Line count 1 to 4
Sets the line count of the print item
1.
10 41 Line spacing 0 to 2
Sets the line spacing of the print
item 1.
10 42 Character size 1 to 13
Sets the character size of the print
item 1.
1:4x5 , 2:5x5 , 3:5x8(5x7)
4:9x8(9x7) , 5:7x10 , 6:10x12
7:12x16 , 8:18x24 , 9:24x32
10:11x11 , 11:5x3(chimney)
12:5x5(chimney), 13:7x5(chimney)
10 43 Inter-character space 0 to 28
Sets the inter-character space of
the print item 1.
10 44 Bold 1 to 9 Sets the bold of the print item 1.
10 45 Bar code 0 to 26
Sets the bar code of the print item
1.
0:none , 1:Code 39 , 2:ITF
3:NW-7 , 4:EAN-13 , 5:DM8x32
6:DM16x16 , 7:DM16x36
8:DM16x48 , 9:DM18x18
10:DM20x20 , 11:DM22x22
12:DM24x24
13:Code 128 (Code set B)
14:Code 128 (Code set C)
15:UPC-A , 16:UPC-E , 17:EAN-8
18:QR21x21 , 19:QR25x25
20:QR29x29 , 22:EAN-13add-on 5
23:MicroQR15x15
24:GS1 DataBar (Limited)
25:GS1 DataBar (Omnidirectional)
26:GS1 DataBar (Stacked)
10 46 EAN readable code 0 to 2
Sets the EAN readable code of the
print item 1.
0:none , 1:5x5 , 2:5x7
10 47 EAN Prefix 0 to 99
Sets the EAN prefix of the print
item 1.
10 48 Calendar block No. 0 to 8
When writing, setting is NOT
required. When reading, Block
information can be obtained item
by item.
10 49 Calendar block count 0 to 8
10 4A Count block No. 0 to 8
10 4B Count block count 0 to 8
10 4C Horizontal (X) 0 to 31998
Valid when Free layout is set.
Sets the
coordinate of the print
item 1.
10 4D Vertical (Y) 0 to 29
10 4E Reserve_1
-
"Reserve" is not initially provided,
but may be added in future.
… …
10 57 Reserve_10
