Hitachi Virtual Storage Platform G600 Reference Guide

Number Item Description
1 STATUS LED
Green: Front end module is in
the power-on state.
Red: Front end module can be
removed safely.
2
PORT LED Red: Small form factor
pluggable can be removed.
Blue: Normal link status at 16-
Gbps.
Green: Normal link status at 4-
Gbps or 8-Gbps.
3
Fibre Channel connectors Connect to Fibre Channel
cables.
Port assignments
CHB number
16-Gbps Fibre Channel Ports (left to right)
Port 1 Port 2
CHB-1A 1A 3A
CHB-1B 1B 3B
CHB-1C 1C 3C
CHB-1D 1D 3D
CHB-1E 1E 3E
CHB-1F 1F 3F
CHB-1G 1G 3G
CHB-1H 1H 3H
CHB-2A 2A 4A
CHB-2B 2B 4B
CHB-2C 2C 4C
CHB-2D 2D 4D
CHB-2E 2E 4E
CHB-2F 2F 4F
CHB-2G 2G 4G
CHB-2H 2H 4H
LAN blade LEDs and connectors
38 Host, Network, and Drive Tray Ports and LEDs
Hitachi Virtual Storage Platform G400, G600 Hardware Reference Guide
