Number Description
These ports connect to your IP network, the
management console PC, and the user LAN port
on each storage system controller.
Note: After the Initial Startup Wizard is run, the SVP can be used in non-
bridge mode. In this mode, the cables can be removed from SVP ports LAN3
and LAN4 and attached to switches. For more information, contact customer
support.
Service processor hardware specifications
The following table lists the hardware specifications for the service processor
(SVP) provided by Hitachi Data Systems.
Caution: The SVP is not supported in high-temperature environments. Do
not operate it in locations with temperatures of 40°C or higher.
Item Specification
Dimensions Height: 1.7 inches (43 mm)
Width: 17.2 inches (437 mm)
Depth: 14.5 inches (369 mm)
Weight: 14 lbs (6.4 kg)
Processor Celeron G1820 2.7-GHz 2M, 2C, 2T
• Cores: 2
• Instruction set: 64-bit
• SmartCache: 2 MB
• Maximum memory size: 32 GB
• Memory types: DDR3-1333, DDR3L-1333 @
1.5V
Memory 8-GB RAM DDR3
Hard drive 2 TB
Network interface card x4 ports (on-board NIC) +
x1 IPMI (BMC) port
Fans 2 x 4-cm 4-pin PWM fans
Operating system Windows Embedded Standard 7
64 VSP service processor server
Hitachi Virtual Storage Platform G400, G600 Hardware Reference Guide
