Number Item Description
1 STATUS LED
Green: Back end module is in
the power-on state.
Red: Back end module can be
removed safely.
2 Port LED Blue: Link status is normal.
3 PATH 0 connector Connect to a drive tray.
4 PATH 1 connector Connects to a drive tray.
40 Host, Network, and Drive Tray Ports and LEDs
Hitachi Virtual Storage Platform G400, G600 Hardware Reference Guide
