- 17 -
Func.
Code
Name / Description
Default
-FE/FU
Set
value
B083 Carrier frequency setting 3.0
B084 Initialization mode (parameter or trip history)
y 00 Trip history clear
y 01 Parameter initialization
y 02
Trip history clear and parameter initialization
00
B085 Country code for initialization
y 00 Japan version y 01 Europe version
y 02 US version
01/02
B086 Frequency scaling conversion factor 1.0
B087 STOP key enable
y 00 Enable y 01 Disable
00
B088 Restart mode after FRS
y 00 Restart from 0Hz
y 01 Restart with frequency pull-in
00
B089 Data select for digital operator OPE-J
y 01 Output frequency (d001)
y 02 Output current (d002)
y 03 Motor direction (d003)
y 04 PID PV feedback (d004)
y 05 Input status for input terminals (d005)
y 06 Output status for output terminals (d006)
y 07 Scaled output frequency (d007)
01
B091 Stop mode selection
y 00 DEC (decelerates and stop)
y 01 FRS (free-run to stop)
00
B092 Cooling fan control
y 00 Fan is always ON
y 01 Fan is ON during run, OFF during stop (5
minutes delay from ON to OFF)
y 02 Fan is temperature controlled
00
B130 Over-voltage LADSTOP enable
y 00 Disable y 01 Enable
00
B131 Over-voltage LADSTOP level 380,760
B133 DC bus AVR selection
y 00 Disable y 01 Enable
00
B134 Threshold voltage of DC bus AVR setting 380,760
B140 Over-current trip suppression
y 00 Disable y 01 Enable
00
B150 Automatic carrier control
y 00 Disable y 01 Enable
00
B151 Selection of RDY function 00
