“A” group: Standard Functions
Func.
Code
Name / Description
Default
-FE/-FU
Set
value
A001/
A201
Frequency source setting
y 00 Keypad potentiometer
y 01 Control terminal
y 02 Function F_01 setting
y 03 RS485 Modbus communication
y 10 Calculate function output
01/00
A002/
A202
Run command source setting
y 01 Input terminal FW or RV (assignable)
y 02 RUN key on the keypad
y 03 RS485 Modbus communication
01/00
A003/
A203
Base frequency setting 50/60
A004/
A204
Maximum frequency setting 50/60
A005 [AT] selection
y 02 Select [O] or POT by [AT] terminal input
y 03 Select [OI] or POT by [AT] terminal input
y 04 [O] input only y 05 [OI] input ony
Not assigned [AT] is the same as [AT]=OFF.
02
A011 O-L input active range start frequency 0.0
A012 O-L input active range end frequency 0.0
A013 O-L input active range start voltage 0.
A014 O-L input active range end voltage 100.
A015 O-L input start frequency enable
y 00 Use A011 (starting value) y 01 Use 0Hz
01
A016 External frequency filter time constant 8.
A020/
A220
Multi-speed frequency setting 0.0
A021~
A035
Multi-speed frequency settings
(for both motors)
0.0
A038 Jog frequency setting 1.0
A039 Jog stop mode
y 00 Free-run stop, jogging disabled during motor run
y 01 Controlled deceleration, jogging disabled during
motor run
y 02 DC braking to stop, jogging disabled during motor
run
00
A041/
A241
Torque boost method selection
y 00 Manual torque boost
y 01 Automatic torque boost
00
A042/
A242
Manual torque boost value 1.8(A042)/
0.0(A242)
A043/
A243
Manual torque boost frequency adjustment 10.0(A043)/
0.0(A243)
A044/
A244
V/f characteristic curve selection
y 00 V/f constant torque
y 01 V/f variable torque
y 06 V/f variable torque1
00
A005 02 03 04 05
AT input OFF ON OFF ON OFF ON OFF ON
Active [O] POT [OI] POT [O] [OI]
