Hitachi X200 Series - C Group: Intelligent Terminal Functions

- 18 -
“C” group: Intelligent Terminal Functions
Func.
Code
Name / Description
Default value
-FE/FU
Set
value
C001/
C201
Terminal [1] function 00
C002/
C202
Terminal [2] function 01
C003/
C203
Terminal [3] function 02/16
C004/
C204
Terminal [4] function 03/13
C005/
C205
Terminal [5] function
Thirty one option
codes available
(See page 20)
18
C011 Terminal [1] active state 00
C012 Terminal [2] active state 00
C013 Terminal [3] active state 00
C014 Terminal [4] active state 00/01
C015 Terminal [5] active state
y 00 Normally
open [NO]
y 01 Normally
closed [NC]
00
C021 Terminal [11] function Twelve option codes
available
(See page 20)
01
C026 Relay output function Twelve option codes
available
(See page 20)
05
C028 AM signal selection
y 00 motor speed y 01 motor current
00
C031 Terminal [11] active state 00
C036 Alarm relay terminal active
state
y 00 Normally
open [NO]
y 01 Normally
closed [NC]
01
C038 Output mode of low load current
y 00 Disabled
y 01 During accel, decel and constant speed
y 02 During constant speed only
01
C039 Low load detection level INV Rated
current
C041/
C241
Overload output signal level setting INV Rated
current
C042 Frequency arrival setting for accel 0.0
C043 Frequency arrival setting for decel 0.0
C044 PID deviation level setting 3.0
C052 PID PV high limit 100.0
C053 PID PV low limit 0.0
C070 Selection of OPE/ModBus
y 02 OPE y 03 ModBus
02
C071 Communication speed selection
y 04 4800bps y 05 9600bps y 06 19200bps
06/04
C072 Node allocation 1.
C074 Communication parity selection
y 00 No parity y 01 Even parity
y 02 Odd parity
00
C075 Communication stop bit selection 1
C076 Communication error select
y 00 Trip (error codeE60)
y 01 Decelerate to stop and trip (error code E60)
y 02 Disable y 03 Free run stop (coasting)
02
