- 20 -
Intelligent Input Terminal Listing
Symbol Code Input Terminal Name
FW 00 Forward Run/Stop
RV 01 Reverse Run/Stop
CF1 02 Multi-speed select, Bit 0 (LSB)
CF2 03 Multi-speed select, Bit 1
CF3 04 Multi-speed select, Bit 2
CF4 05 Multi-speed select, Bit 3 (MSB)
JG 06 Jogging
DB 07 External DC braking
SET 08 Set (select) 2
nd
motor data
2CH 09 2-stage accel and decel
FRS 11 Free-run stop
EXT 12 External trip
USP 13 Unattended start protection
SFT 15 Software lock
AT 16 Analog input voltage/current selection
RS 18 Reset inverter
PTC 19 PTC thermistor thermal protection
STA 20 Start (3-wire interface)
STP 21 Stop (3-wire interface)
F/R 22 FWD,REV (3-wire interface)
PID 23 PID disable
PIDC 24 PID Reset
UP 27 Remote control Up function
DWN 28 Remote control Down function
UDC 29 Remote control data cleaning
OPE 31 Operator control
ADD 50 Add frequency enable
F-TM 51 Force Terminal Mode
RDY 52 Inverter ready
SP-SET 53 Special set
EMR 64 Emergency stop
- 255 (No function)
Intelligent Output Terminal Listing
Symbol Code Output Terminal Name
RUN 00 Run signal
FA1 01 Freq. arrival type 1 – constant speed
FA2 02 Freq. arrival type 2 – over-frequency
OL 03 Overload advance notice signal
OD 04 Output deviation for PID control
AL 05 Alarm signal
Dc 06 Analog input error
FBV 07 PID second stage output
NDc 08 Network error
LOG 09 Logic output function
ODc 10 Communication option error
LOC 43 Low load detection
