Hitachi X200 Series

IGBT Test Method
The following procedure will check the inverter transistors (IGBTs) and diodes:
1
. Disconnect input power to terminals [R, S, and T] and motor terminals [U, V, and W].
2
. Disconnect any wires from terminals [+] and [–] for regenerative braking.
3
. Use a Digital Volt Meter (DVM) and set it for 1 resistance range. You can check the
status of the charging state of terminals [R, S, T, U, V, W, +, and –] of the inverter
and the probe of the DVM by measuring the charging state.
T
able Legend Almost infinite resistance: #  Almost zero resistance: # 0 
DVM DVM DVMPart
+ –
Measured
Value
Part
+ –
Measured
Value
Part
+ –
Measured
Value
[R][+1]
# 
[S][–]
# 0 
[W][+]
# 
D1
[+1][R]
# 0 
D5
[
–
][S]
# 
TR3
[+][W]
# 0 
[S][+1]
# 
[T][–]
# 0 
[U][–]
# 0 
D2
[+1][S]
# 0 
D6
[
–
][T]
# 
TR4
[
–
][U]
# 
[T][+1]
# 
[U][+]
# 
[V][–]
# 0 
D3
[+1][T]
# 0 
TR1
[+][U]
# 0 
TR5
[
–
][V]
# 
[R][–]
# 0 
[V][+]
# 
[W][–]
# 0 
D4
[
–
][R]
# 
TR2
[+][V]
# 0 
TR6
[
–
][W]
# 
NOTE: The resistance values for the diodes or the transistors will not be exactly the
same, but they will be close. If you find a significance difference, a problem may exist.
NOTE: Before measuring the voltage between [+] and [–] with the DC current range,
confirm that the smoothing capacitor is discharged fully, then execute the tests.
