Installation for X200 series (example of SFEF models)
*) Both earth portions of the shielded cable must be connected to the earth point by
cable clamps.
D4
Appendix D
L1,N
PE
Cable clamp *
Shielded cable
Power supply
1-ph. 200V
Motor
3~
Cable clamp *
P
E
U,V,W
Metal plate (earth)
