Hitachi X200 Series - Trip Event and History Monitoring

“D” Function
Func.
Code
Name /
SRW Display
Description
Run
Mode
Edit
Units
Scaled output frequency
monitor
D007
F-Cnv 00000.00
Displays the output frequency
scaled by the constant in B086.
Decimal point indicates range:
XX.XX 0.00 to 99.99
XXX.X 100.0 to 999.9
XXXX. 1000. to 9999.
XXXX 1000 to 9999
(x10=10000 to 99999)

Hz times
constant
Output voltage monitorD013
Vout 00000V
Voltage of output to motor,
Range is 0.0 to 600.0V

V
Cumulative operation
RUN time monitor
D016
RUN 0000000hr
Displays total time the inverter has
been in RUN mode in hours.
Range is 0 to 9999 / 1000 to 9999 /
ª
100 to ª999 (10,000 to 99,900)

hours
Cumulative power-on time
monitor
D017
RUN 0000000hr
Displays total time the inverter has
been powered up in hours.
Range is 0 to 9999 / 1000 to 9999 /
ª
100 to ª999 (10,000 to 99,900)

hours
Cooling Fin temperature
monitor
D018
TH-Fin 0000.0 C
Temperature of the cooling fin.
(0.0~200)
qC
Trip Event and History Monitoring
The trip event and history monitoring feature lets you cycle through related information
using the keypad. See “Monitoring Trip Events, History, & Conditions” on page 6-5 for
more details.
“D” Function
Func.
Code
Name /
SRW Display
Description
Run
Mode
Edit
Units
Trip counterD080
ERR CNT 00000
Number of trip events,
Range is 0. to 9999

events
Trip monitor 1D081
ERR1 ########

Trip monitor 2D082
ERR2 ########

Trip monitor 3D083
ERR3 ########
Displays trip event information:
x Error code
x Output frequency at trip point
x Motor current at trip point
x DC bus voltage at trip point
x Cumulative inverter operation
time at trip point
x Cumulative power-ON time at
trip point

DC bus voltage monitorD102
Vpn 0000.0Vdc
Voltage of inverter internal DC bus,
Range is 0.0 to 999.9

V
Electronic thermal monitorD104
E-THM 0000.0%
Accumulated value of electronic
thermal detection, range is from 0.0
to 100.0

%
