Miscellaneous—Specifications
TX14740,0001F28 –19–12NOV02–2/2
Item Measurement Specification
6—Cab Height 4962 mm (16 ft 4 in.) With 48 in.
Riser
5474 mm (18 ft 0 in.) With 72 in.
Riser
7—Minimum Ground Clearance Distance 687 mm (2 ft 3 in.)
8—Center Of Sprocket To Center Of Distance 2913 m (9 ft 7 in.)
Sprocket
9—Track Shoe Width 700 mm (28 in.)
10—Track Shoe Height 1262 mm (4 ft 2 in.)
11—Machine Overall Length 15756 mm (51 ft 8 in.)
Machine Operating Weight 44,693 kg (98,530 lb)
4-6-38 081407
PN=237
