20
Memory Preset - Data Save/Load
Safety Time
ON 900 Min
Safety timer ON and duration of time in minutes.
Capacity cut-off ON and the setting value of
capacity.
→
→
DEC
►
Capacity Cut-Off
ON 5000mAh
Memory Preset - Data Save/Load:
The Save Data and Load Data programs make it easy to store and load charge and discharge pro les for up
to 10 batteries per channel. Data can be saved for each battery type and each charge mode available with
the RDX1 Mini. This allows you to recall data for each battery when charging or discharging without having
to set up the program over again. You can also edit settings for each saved battery.
Save Data:
From the BATT/PROGRAM menu use the + or - buttons to scroll to the
BATT MEMORY program and press the ENTER/Start►button to enter
the battery memory program. In the corner of the screen you will see the number 1 ashing, use the
+ or - buttons to scroll through the memories. When you are ready to select a memory to program,
press the ► button again to enter the memory setup menu.
Press the ►button again and the battery type will begin to ash.
Use the + or - buttons to select the battery type (LiPo, LiFe, LiIon,
LiHV, NiMH, NiCd or Pb, then press the ► button to con rm your selection.
Now you will use + or - buttons to scroll through the battery parameters, using the + you will make
adjustments in the following order, using the - button will reverse this order.
Voltage and Number of Cells: Press the ► button and the
number of cells will begin to ash. Use the + or - buttons to change the
cell count then press the ►button to con rm your selection.
Charge Current: Press the ►button and the charge current value
will begin to ash. Use the + or - buttons to change the charge
current then press the ► button to con rm your selection.
[BATT MEMORY 1]
ENTER SET ->
BATT TYPE
LiPo
BATT VOLTS
7.4V ( 2S )
CHARGE CURRENT
4.9A
To Next Page
