Appendix A CS-310/320 Specification
Model Name CS-310 CS-320
Print Method
Photo-quality dye sublimation Thermal Transfer Dual-side Printing
*
Resolution
300dpi x 300dpi , 256 levels per color
Display
LCD control panel
Memory
32MB, 1MB Flash
Print Speed
Standard Mode : 25 seconds / single side ; Premium Photo Mode : 32 sec / single side
Print Area
CR-80 edge-to-edge 86 mm(L) x 54 mm(W) / 3.375"(L) x 2.125"(W)
Accepted card
Specification
Size : CR-80 edge-to-edge 86 mm(L) x 54 mm(W) / 3.375"(L) x 2.125"(W)
Thickness : 0.3 mm to 1.0 mm ( 10 mil to 40 mil )
Input hopper card
capacity
100 cards (30 mil thickness)
Output hopper card
capacity
100 cards (30 mil thickness)
Software driver
Windows 2000 / XP/Vista
Communication Interface
USB 1.1/ USB 2.0 full speed
System request
IBM-PC or compatible, Windows 2000/XP/Vista, Pentium® class 133MHz
computer with 128 MB of RAM or higher, 100MB free hard disk space or higher.
Ribbon Options
YMCKO (200 Prints), YMCO (200 Prints)
**, YMCKOK(170 Prints)**
Resin K (1.000 Prints), KO (500 Prints )
**
Lamination (350 Prints)
**
Gold (1.000 Prints) **
Silber (1.000 Prints) **
Dimensions
275 mm (W) x 508 mm (L) x 251 mm (H) / 10.83”(W) x 20”(L) x 9.88”(H)
Weight 9.1 kg / 20lbs
Supply Voltage
100~240 VAC
Supply Frequency
50 Hz ~60 Hz
Operating Temperature
15° to 32° C / 59° to 89.6° F
Operating Humidity
20 - 75% non-condensing
Optional Module
ISO Magnetic Stripe Encoding Module**, dual high- and low-coercively, Tracks 1, 2, an
d
3, Contact-less Smart Card Encoding Module**,Contact Smart Card Encoding
Module
**, Lamination Module**
Cleaning tool
HiTi Card Printer Cleaning Kit, HiTi Card Printer Cleaning Module
*CS-310 supports single-side printing only.
**Please contact the Sales Department or the Customer Service Department for any further
information.
