HMS Anybus CompactCom 30 User Manual

Network Specific — PROFINET 37 (38)
13.13.3 Keywords
Keyword Comments
GSDML-DeviceProfile version 2.31 for 30-series, 2.32 for 40-series
DeviceIdentity->DeviceID Must be changed to reflect the Device ID you have configured
in the PROFINET IO object (F6h), Attribute 1.
DeviceAccessPointItem->CheckDeviceID_
Allowed
False for 30-series, true for 40-series
DeviceAccessPointItem-
>ImplementationType
NP30 for 30-series, NP40 for 40-series
DeviceAccessPointItem->WebServer Optional keyword. Can be removed if not used.
DeviceAccessPointItem->LLDP_NoD_
Supported
Manadatory, =true for 40-series
DeviceAccessPointItem-
>PowerOnToCommReady
Required if Fast Start-Up is supported
DeviceAccessPointItem-
>ResetToFactoryModes
2 in 30-series, 2 and 8 in 40-series (2 mandatory)
DeviceAccessPointItem->PNIO_Version V2.2 in 30-series, V2.32 in 40-series
ModuleInfo->HardwareRelease Value Optional. Removed in 40-series
ModuleInfo->SoftwareRelease Value Optional. Removed in 40-series
CertificationInfo->ConformanceClass B in 30-series, B or C in 40-series depending on IRT.
CertificationInfo->NetloadClass Mandatory. III in 40-series
VirtualSubmoduleItem->API Removed in 40-series. API=0 default.
VirtualSubmoduleItem->IOData IOPS_
Length
Removed in 40-series. Default=1
VirtualSubmoduleItem->IOData IOCS_
Length
Removed in 40-series. Default=1
VirtualSubmoduleItem->Writeable_IM_
Records
1 2 3 4 in 30-series. 1 2 3 in 40-series.
VirtualSubmoduleItem-
>MayIssueProcessAlarm
Mandatory for 2.32. False in 40-series.
InterfaceSubmoduleItem->PTP_
BoundarySupported
False in 30-series, true in 40-series
InterfaceSubmoduleItem->DCP_
HelloSupported
True - Required if FSU is supported
InterfaceSubmoduleItem-
>DelayMeasurementSupported
Only for IRT (40-series)
InterfaceSubmoduleItem->RT_
Class3Properties
Only for IRT (40-series)
InterfaceSubmoduleItem-
>SynchronisationMode
Only for IRT (40-series)
ApplicationRelations->StartupMode Legacy in 30-series. Legacy and Advance in 40-series
(mandatory).
MediaRedundancy SupportedRole="Client" New MRP keyword in the 40-series. MRP not supported in
30-series.
SupportsRingportConfig="true" New MRP keyword in the 40-series. MRP not supported in
30-series.
IsDefaultRingport="true" New MRP keyword in the 40-series. MRP not supported in
30-series.
VirtualSubmoduleItem->Writeable_IM_Re-
cords="1 2 3"
I&M4 removed in the 40-series
Migrating from Anybus
®
CompactCom
™
30 to Anybus
®
CompactCom
™
40 Design Guide SCM-1202-043 1.1
